Deltawave CoG clamp-on for gases

The deltawaveC-P by systec Controls is a universal, portable clamp-on ultrasonic flowmeter. It delivers precise, non-intrusive flow and thermal energy measurement for liquids in filled pipes. Operating with a built-in data logger and battery power, it eliminates pipe cutting and process downtime

  • Non-Invasive Setup: Straps entirely to the outside of the pipe with zero pressure loss or risk of leakage.
  • High-Precision Technology: Uses the digital ultrasonic transit-time method to log 50 to 150 measurements per second.
  • Versatile Application: Measures pipe diameters from DN10 to DN6000 and fluid temperatures up to 150°C (380°C with high-temp sensors).
  • Built-in Intelligence: Includes standard thermal energy/heat metering, an integrated data logger, and a fast “Quick Setup” parameterization tool.



4 People watching this product now!
SKU: Deltawave C-P-1 Categories: ,
Description

Description

Dive into the field of high-precision, non-contact ultrasonic gas flow measurement with deltawaveCoG, expertly developed for accurate clamp-on gas (CoG) flow measurement that seamlessly combines ease of use and careful attention to airflow and gases in pipelines. This specialized system from systec Controls incorporates the latest technologies in compressed air monitoring and natural gas flow measurement using a non-intrusive, clamp-on method that ensures the operational integrity of the pipeline.


Simple and safe: Ultrasonic flow meter for gas using clamp-on technology

Ultrasonic flow meter for gas deltawaveCoG, using state-of-the-art time-of-flight measurement, proves its precision and reliability not only in the field of compressed air monitoring, but also for various gases. It works perfectly as a flow meter for natural gas as well as for compressed air monitoring. The brilliance of clamp-on technology is that no direct contact with the medium is required. The ultrasound gas flow meter transducers are mounted on the outside of the pipe, allowing processes to continue undisturbed and maintaining the integrity of the pipe. This technology provides 100% leak- and wear-free gas flow measurement and constant compressed air monitoring.


Precise and comprehensive data acquisition

To ensure accurate and comprehensive data acquisition, ultrasound gas flow meter deltawaveCoG is also an integrative volume corrector, providing a variety of values including flow rate, volume, standard flow and total mass, among others. It also harmonizes the compensation and acquisition of pressure and temperature values via analog inputs and PT100.

Reliable and user-friendly: the ultrasound gas flow meter deltawaveCoG

The technology of ultrasonic gas flow meters is thoroughly incorporated in the deltawaveCoG, which is not only a reliable ultrasonic gas flow meter, but in addition is suitable for a variety of application scenarios. With a clear graphical display and accelerated setup options, the flow meter for (natural) gas deltawaveCoG can be parameterized in a remarkably short time, guided by the integrated on-screen help. The auto-optimizer optimally adapts the measurement parameters to your line. And the robust mounting kit allows for quick and stable installation of the transducers.

Transducers have never been mounted so fast!

Advantages of deltawaveClamp-on-Gas (deltawaveCoG) at a glance

  • 100% Contact-free with the medium
  • 100% Wear-free
  • 100% Leakage proof
  • 100% Hygienic
  • 100% Pressure loss free

Specifications

PrincipleUltrasonic time of flight
Pressure and temperature compensationIntegrated
– Input of pressure and temperature as default value
– Input of pressure and temperature as 4 … 20 mA analogue value
– Measurement of the temperature by means of PT100
Pipe Sizes25…700 mm
Pipe materialsCarbon steel, stainless steel, plastics
MountingZ-mode
Mounting typeFluid-contact-free with clamp on transducers
Flow range-30…30 m/s
MeasurementFlow rate, flow velocity, standard volume flow
TotalizerVolume, standard volume
Inputs2x 4…20mA (pressure and temperature)
2x PT100 (3-wire)
Outputs1x relay, 2×4…20mA, 1x digital (transistor), 1x USB socket (Mini B)
Interfaces (optional)RS485, Modbus,
Power supply230VAC bzw. 18-36VDC
Protection classIP65
MediaAir and natural gas, other gases possible on request
Media Temperature-40….150°C

Ultrasonic gas flow meter deltawaveCoG: Safe in hazardous areas

Navigating in hazardous areas, our ultrasonic flow meter for gas deltawaveCoG guarantees maximum safety in the application, as both the electronics (Eex-d or Eex-n) and the clamp-on transducers (Ex-q) are Ex-approved. This opens the way for optimal safety, allowing the combination of Ex and non-Ex components as required, effectively saving money without compromising safety.

For example, if only a small radius around the pipeline is in the hazardous area, you can place the non-Ex electronics outside the hazardous area. Simply order the ultrasonic transducers in the Ex version. Your benefit: lower costs without compromising safety.

Applications for clamp-on gas flow measurement

  • Power plants: Reliable measurement and monitoring of natural gas consumption
  • Mechanical Engineering: Compressed air billing and consumption optimization
  • Gas utilities: Replacement of mechanical meters on transmission pipelines or pressure reducing stations
  • LNG terminals: gas acceptance, odor control
  • Chemical and petrochemical industries: Safe flow measurement of hazardous and toxic gases
