Digital Display for Capacitance Transmitter

In stock

SKU: eds
The EDS Digital Display (two-wire electrical connection) is designed to be mounted on the pressure, differantial pressure, flow, temperature andlevel transmitters. LCD Displays show, the value measured in the real-time and it will flash to alarm. The three button feature allows the user to program the zero, span, unit, decimal digits, damping and alarm point. download pdf datasheet
Quick view

Digital Pressure Gauge 0.05% DTG 100 High Precision

In stock

SKU: DTG100-005
High accuracy, (±0.05% FS) - 5 digit LCD backlight display Long term precise pressure readings with inbuilt temperature compensation, zero point calibration, overload alarm, light weight Alu Alloy cover, SS bottom connection, CE approval, 2 year operation with dry cell Lithium batteries. download pdf datasheet
Quick view

Digital Pressure Gauge 0.1% DTG 100 Standard

In stock

SKU: DTG100-01
Accuracy, (±0.1% FS) - 5 digit LCD backlight display Long term precise pressure readings with inbuilt temperature compensation, zero point calibration, overload alarm, light weight Alu Alloy cover, SS bottom connection, CE approval, 2 year operation with dry cell Lithium batteries. download pdf datasheet
Quick view

Digital Pressure Gauge 0.5% DTG 100 Standard

In stock

SKU: DTG100-05
Accuracy, (±0.5% FS) - 5 digit LCD backlight display Long term precise pressure readings with inbuilt temperature compensation, zero point calibration, overload alarm, light weight Alu Alloy cover, SS bottom connection, CE approval, 2 year operation with dry cell Lithium batteries. download pdf datasheet
Placeholder
Quick view

Digital Pressure Gauge DTG 200 High Pressure & Precision

In stock

SKU: DTG200
High pressure (up to 2500 bar) - High accuracy, (up to ±0.025% FS) 6 digit LCD backlight display, Long term precise pressure readings for power, chemical, petrol, metallurgy industries: inbuilt temperature compensation, zero point calibration, min/max values, rugged ABS plastic, dual readout, rechargeable Lithium battery, CE approval, RS 232 communication with PC download pdf datasheet
Quick view

Dosing System FMD Massflow

In stock

SKU: FMD
The dosing mass flow meter extends the range of dosing sensors with a special focus on the dosing of non-conductive media and direct mass dosing. download pdf datasheet FMD Massflow Meter
Quick view

Dosing System MID-MDS conductive liquids

In stock

SKU: MID-MDS
Modular dosing system (MDS) for filling conductive liquids in filling machines with electromagnetic flowmeters download pdf datasheet El-Mag FM
Quick view

Dosing System MID-MDS conductive liquids

In stock

SKU: MID-MDS
Modular dosing system (MDS) for filling conductive liquids in filling machines with electromagnetic flowmeters download pdf datasheet El-Mag FM
Quick view

Dosing System MID-MDS ECO conductive liquids

In stock

SKU: MID-MDS ECO
Compact magnetic inductive flowmeter for filling conductive liquids in filling machines download pdf datasheet El-Mag FM
Quick view

Dosing System OD non-conductive liquids

In stock

SKU: OD
The focus is on the measurement of non-conductive liquids. This meter is designed for the measurement of e.g. oil or demineralized water. Due to the measuring principle, an inlet or outlet section is not required. download pdf datasheet OD Flow Meter
Quick view

Dryblock Temp. Calibrator TE

In stock

SKU: TE Serie
The Presys TE series consists of compact, cost-effective dry block calibrators combine a highly stable temperature source with an integrated signal measurement system to eliminate the need for carrying secondary instruments like digital multimeters.
Core Features
  • 3-in-1 Functionality: Acts as a dry block heat source, a reference standard thermometer, and an electronic signal calibrator all in one portable unit.
  • Built-In Measurement: Features an internal indicator that measures RTDs, thermocouples, current (mA), voltage (mV), and resistance (Ohms).
  • Loop Power Supply: Provides an internal 24 Vdc power source to energize 2-wire transmitters during field testing.
  • Thermoswitch Testing: Includes a dedicated automatic test function to identify and record the precise trip and reset points of temperature switches.
Quick view

Dynamic Flap flow sensor w display – liquids

In stock

SKU: MEFS-F
ME Series Dynamic Flap flow sensor with display for liquids
Quick view

Electro Magnetic Flow Meter SSEAMFI

In stock

SKU: SSEAMFI
The Schmierer SEA Electro Magnetic Flowmeter Range is based on Faraday's Law of Electromagnetic Induction. When the conductive fluid flows through a magnetic field of the sensor, an electric voltage proportional to the volume flow is generated between the pair of electrodes and transmitted to the output device. The flow and volume will be displayed at the electronic transmitter No disturbance or restriction of flow No moving parts - no wear and tear, virtually no pressure loss Insensitive to fluid density, temperature, pressure, viscosity Can be used for different types of conductive liquids (calibration with water required) download pdf datasheet
Quick view

Electro Magnetic Flow Meter SSEAMFII

In stock

SKU: SSEA MFII
The SSEAMFII series electromagnetic flowmeter is suitable for the conductive medium with a conductivity higher than 5μs / cm. It is composed of the sensor and converter, and the sensor consists of measuring tube, electrodes, excitation coils, iron core and shell and other components. After the traffic signal is amplified, processed and operated by converter, you can see the instantaneous flow, cumulative flow, output pulse, analog current and other signals for the measurement and control of fluid flow. It adopts the smart converter so that it not only has the measurement, display and other functions, but also supports the remote data transmission, wireless remote control, alarm and other functions. ◆ Excellent measurement repeatability and linearity ◆ Good reliability and anti-interference performance ◆ Good pressure resistance sealing ability ◆ Low pressure loss measurement tube ◆ High intelligentization ◆ Maintenance-free download pdf datasheet
Quick view

Electro Magnetic Flow Meter SSEAMFIII

In stock

SKU: SSEA MFIII
The SSEAMFIII Electro-Magnetic Flow meter is a volumetric FM with no moving parts - for conductive water-based liquids - ideal for waste water applications or any dirty liquid - low pressure drop and low maintenance - Max Temperature 180°C with PFA lining. download pdf datasheet
Quick view

Electro Magnetic Flowmeter SpiraMag

In stock

SKU: SpiraMag
The field of application for all electromagnetic flowmeters of the SpiraMAG® series is the measurement of conductive liquids (>5µS/cm) like water, waste water in continuous flow measurement. The series comprises the nominal diameters DN 15 to DN 1000 and is available in the pressure stages PN 10/16/40. The standard maximum temperature is 60°C. download pdf datasheet
Quick view

Electro Magnetic Sanitary Flow Meter SSEAMFIII

In stock

SKU: SSEA MFIII San
The SSEAMFIII Sanitary Electro-Magnetic Flow meter is one of the most flexible and universally applicable flow measurement systems available. It is volumetric flow meter which does not h ave any moving parts and is ideal for waste water applications or any dirty liquid which is conductive or water based. Magnetic flow meter is also ideal for the applications where low pressure drop and low maintenance are required. Max Temperature 180°C with PFA lining. download pdf datasheet
Quick view

Exchangeable Measuring Insert 1200°C WD 610 ceramic cover

In stock

SKU: WDJ, WDK
Measuring insert in a ceramic cover (mullite 610), with a terminal block. Large diameters of the thermocouple wire enable long-term measurement of high temperatures.
Quick view

Exchangeable Measuring Insert 550°C WM2 mineral insulated

In stock

SKU: WM2P, WM2J, WM2K
Mineral insulated metal sheathed insert is used as a replaceable element of temperature sensors. Insert design enables its installation in the connection head and pressing insert tip to the bottom of the sensor thermowell.
Quick view

Exchangeable Measuring Insert 600°C WM1

In stock

SKU: WM1P, WM1J, WM1K
Measuring insert in the pipe, rigid sheath is used as a replaceable element of temperature sensors. Insert design enables its installation in the connection head and pressing insert tip to the bottom of the sensor thermowell.
